BA505 – Latest A Series The most feature-rich SNMP card
BA505 – Latest A Series The most feature-rich SNMP card
The BA505, as a mainstream card in the latest A series of SNMP cards, not only integrates and inherits all the functions of the previous T/X/Y series but also adds many practical new features and enhances security.
The BA505 has improved the security of access methods, increased the diversity of event notifications, refined the statistics of UPS data, and expanded the ways for third parties to obtain UPS data.
The BA505, as a mainstream card in the latest A series of SNMP cards, not only integrates and inherits all the functions of the previous T/X/Y series but also adds many practical new features and enhances security.
The BA505 has improved the security of access methods, increased the diversity of event notifications, refined the statistics of UPS data, and expanded the ways for third parties to obtain UPS data.
Data statistics
Enumerate the event records in days in calendar form and make statistics in pie charts. The UPS data changes in days are displayed in a linear graph, and the data statistics are carried out, showing the maximum value, minimum value, average value, variance and standard difference.
Network Connection
Support traditional wired network access; Support inserting compatible USB wireless network card for wireless network access; You can also enable the BA505 hotspot function to access the BA505 web management interface in an environment without a network.
Event notification
Support the original UPS event notification by email and SMS; Added UPS event notification via wechat, Skype, Telegram and LINE.
Access Method
Support HTTPS access, HTTPS protocol supports the latest TLS v1.3, public key length supports 2048 bits; Support HTTP/HTTPS, TELNET/SSH, FTP/FTPS three modes of independent account and password Settings, and can record the login or exit time and IP address; For HTTP/HTTPS or TELNET/SSH login, you can enable the RADIUS or LDAP service for login authentication. Users can also set the automatic upgrade of BA505 through FTP.
Get data
Support through SNMP access third-party monitoring platform, and support for the latest security level v3 version, MD5 authentication protocol/SHA/SHA244 / SHA256 / SHA384 / SHA512, private protocol support DES/AES - 128 / AES - 192 / AES - 256. UPS data monitored by BA505 can be obtained through Modbus, and can be connected through TCP or RS485 interface. Support BACnet to obtain UPS data monitored by BA505; And users can turn on or off Modbus and BACnet services according to their own network security requirements; Log in and out time and IP address of SNMP, Modbus or BACnet.
File management
Add file management function to the web management interface, you can visually view the log files in BA505 and the files that have been connected to the U disk; This function can be used to upload, download or delete BA505 log files or U disk backup log files or firmware files; Using the firmware files in the USB flash drive, you can use the Netility Web function in the web management interface to upgrade the firmware of other SNMP cards (including other series) in the same LAN. Added the Syslog function to automatically back up event logs and UPS data logs to the Syslog server.
Network Connection
Support traditional wired network access; Support inserting compatible USB wireless network card for wireless network access; You can also enable the BA505 hotspot function to access the BA505 web management interface in an environment without a network.
Access Method
Support HTTPS access, HTTPS protocol supports the latest TLS v1.3, public key length supports 2048 bits; Support HTTP/HTTPS, TELNET/SSH, FTP/FTPS three modes of independent account and password Settings, and can record the login or exit time and IP address; For HTTP/HTTPS or TELNET/SSH login, you can enable the RADIUS or LDAP service for login authentication. Users can also set the automatic upgrade of BA505 through FTP.
Get data
Support through SNMP access third-party monitoring platform, and support for the latest security level v3 version, MD5 authentication protocol/SHA/SHA244 / SHA256 / SHA384 / SHA512, private protocol support DES/AES - 128 / AES - 192 / AES - 256. UPS data monitored by BA505 can be obtained through Modbus, and can be connected through TCP or RS485 interface. Support BACnet to obtain UPS data monitored by BA505; And users can turn on or off Modbus and BACnet services according to their own network security requirements; Log in and out time and IP address of SNMP, Modbus or BACnet.
Data statistics
Enumerate the event records in days in calendar form and make statistics in pie charts. The UPS data changes in days are displayed in a linear graph, and the data statistics are carried out, showing the maximum value, minimum value, average value, variance and standard difference.
Event notification
Support the original UPS event notification by email and SMS; Added UPS event notification via wechat, Skype, Telegram and LINE.
File management
Add file management function to the web management interface, you can visually view the log files in BA505 and the files that have been connected to the U disk; This function can be used to upload, download or delete BA505 log files or U disk backup log files or firmware files; Using the firmware files in the USB flash drive, you can use the Netility Web function in the web management interface to upgrade the firmware of other SNMP cards (including other series) in the same LAN. Added the Syslog function to automatically back up event logs and UPS data logs to the Syslog server.
